Centra obróbcze sterowane numerycznie (CNC) (poziomy) MAZAK VORTEX e-1060V/8
maszyny do obróbki metalu / wiertarkofrezarki i centra obróbcze / Centra obróbcze sterowane numerycznie (CNC) (poziomy)
x-travel: 1695 mmy-travel: 1060 mmz-travel: 1345 mmcontrol: MAZATROL MATRIX 2 Table dimensions: 1000 x 1000 mmtable load: kgturning speed range:: 10000 min-1spindle motor: 37 kWspindle taper: BT 50 tool magazin:: 80 Plätzeworkpiece diameter: 1250 x 1200 mmconnected load: 127 kVAweight of the ...
Producent: MAZAK
Model:VORTEX e-1060V/8
Typ maszyny: Centra obróbcze sterowane numerycznie (CNC) (poziomy)
Numer pozycji: 169890334
Ilość: 1
Data: 09.09.2026
Rok produkcji: 2015
Lokalizacja: ab Werksstandort,unter Strom
Cena:
Maszyna w magazynie:Tak
Seller-item-No.:1020-21111
x-travel: 1695 mm
y-travel: 1060 mm
z-travel: 1345 mm
control: MAZATROL MATRIX 2
Table dimensions: 1000 x 1000 mm
table load: kg
turning speed range:: 10000 min-1
spindle motor: 37 kW
spindle taper: BT 50
tool magazin:: 80 Plätze
workpiece diameter: 1250 x 1200 mm
connected load: 127 kVA
weight of the machine ca.: t
dimensions of the machine ca.: 3400 x 7100 x 3379 mm
5-axis machining centre
- MAZATROL MATRIX 2 CNC control
- 2-position pallet changer
- Chip conveyor
- 80-position tool changer (BT 50)
- NC rotary table, 0.0001°
-- B-axis: 150° (120° to -30°)
- C-axis: 360° (table speed: 500)
- Coolant through Spindle
- Oil cooler
- Air through spindle
- Laser measurement (tool)
- Renishaw RPMP 600 touch probe
- Fixture for angle milling head
