6 RAVENSBURG używana maszyna na sprzedaż

faceplate diameter: 1200 mm turning diameter: 1520 mm turning speeds: . U/min max. workpiece weight -without tailstock: 6000 kg max. workpiece weight between centres: 25000 kg Plate area: mm turning diameter in the pit: 3200 mm Control: Siemens turning length: 1200 mm main drive: 70 kW total power requirement: 70 kW weight of the machine ca.: t dimensions of the machine ca.: 22x5x4 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment.  ...

faceplate diameter: 0 mm turning diameter over slide rest: 900 mm turning length: 1.000 mm total power requirement: 25 kW weight of the machine ca.: 8 t dimensions of the machine ca.: m Height of centres 550 mm Max. turning Æ 1200 mm Max. turning Æ over slides, approx. 900 mm Max. turning length, approx. 1000 mm Spindle bore, approx. 90 mm 24 spindle speeds 4.3 - 587 rpm Feeds, infinitely variable 1 - 170 mm/min Total load, approx. 25 kW - 380 V - 50 Hz Weight, approx. 8000 kg Accessories/specialities Two separate slides, each equipped with 2-coordinate copying equipment, program controlled by plugboard, strengthened bearings and spindle, hardened and ground guideways, FORKHARDT 3-jaw chuck/ face plate, separate switch cabinet and cooling equipment. This machine ...

Modernizacja w 1998 r. i zmieniona w 2012 r. przez SIRMU Dane techniczne: Skok: 2000 mm Nachylenie platformy: 0-60 Obrót: 360 Średnica stołu: 4500 mm Maksymalne obciążenie stołu: 50 000 kg Średnica płyty: 2250 mm Ruch 4 etapy 1 28 mm/min 2 100 mm/min 3 280 mm/min 4 560 mm/min Przechylanie stołu: 0-60 4 etapy 2 0,7/min 3 2/min 4 4/min. 5 7/min Rotacja tabeli 4 etapy 1 270 mm/min do średnicy 3500 mm 2 890 mm/min 3 2700 mm/min 4 5400 mm/min Waga całkowita: 90 000 kg

Wysokość środka: 700 mm Szerokość środka: 1800 mm Gr. Obieg Ø nad warstwą/przesunięciem: 1300/1740 mm Suwak obrotowy Ø nad podpórką: 740 mm 12 prędkości obrotowych: 3 - 135 obr./min 12 podań: 0,15 - 2 mm/obr.o. Regulacja górnego podparcia: 350 mm Electr. Napięcie: 380 V, 6,6 kW Masa ok: 5,5 t Wymagania miejscowe: 3800 x 1600 x 1700 mm

faceplate diameter: 2650 mm turning diameter over slide rest: 2800 mm turning diameter over plate: 3200 mm turning length: 10000 mm upper slide-adjustment: 250 mm spindle diameter in front bearing: 400 mm spindle turning speed range: 0,35 -1,12 / 1,2 - 56 U/min feed: 0,05 - 18 mm/U workpiece weight: 9000 kg spindle motor: 60 kW max. workpiece weight between centres: 20000 kg Control: total power requirement: - kW weight of the machine ca.: 93 t dimensions of the machine ca.: m - CNC control NUM 1060 - 4-jaw face plate - Steel holder device - Tailstock - Base plate - Roller setting vice - Transverse travel of the top slide: 425 mm - Longitudinal displacement of the main slide in the centre section: 150 mm - Transverse displacement of the centre section on the lower section: 700m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

średnica: 250 mm adapter narzędziowy: 250 długość: 700 mm całkowite zapotrzebowanie mocy: kW waga maszyny ok.: t wymiary maszyny ok.: m
