4 TRIPET używana maszyna na sprzedaż

Tripet TST201CNC nr 3520.17.137 BJ.1987

grinding diameter:3 - 150 mm grinding length:200 mm total power requirement:380V, 50Hz, 30 kW dimensions of the machine ca.:5 x 3 x 2,5 m

Wewnętrzna cylindryczna szlifierka, Tripet Swiss, 1991, Schleifdia. 0,5 - 30 mm, głębokość szlifowania: 50, wysokość środkowa: 102, Osi: Z, Y, U, B, V, , autom. Chuck, ...

internal diameter: 120 mm grinding depth: 200 mm swing diameter: mm total power requirement: 4 kW weight of the machine ca.: t dimensions of the machine ca.: m Grinding diameter, internal, max., approx. 3 - 120 mm Grinding depth, approx. 200 mm Height of centres above rotating workpiece slide 132 mm Max. swing Ø in front of rotating workpiece slide, approx. 450 mm Work spindle admission 40 mm Table stroke, max. (Z axis) 480 mm Workpiece cross adjustment (X axis) 50 mm Turret head cross adjustment (U axis) 50 mm Workspindle head swivelling (B axis) -30 / +45 ° (manual) Speeds of workspindle, infinitely variable 75 - 1,300 rpm Grinding spindle speeds 9,500 - 150,000 rpm Grinding spindle drive 4 kW Total electrical load, approx. 8 kW - 380 V - 50 Hz Weight, approx. 3,000 kg Accessories / Special Features TRIPET (Bruetsch) CNC Control for 3 axes (Z, X and U) with electric hand wheel, with ...
